Calculation of the column foot anchor bolts under the effect of horizontal pressure due to fresh concrete mixture or due to horizontal pressure due to vibration during concreting, horizontal pressure due to vibration of concrete mixture formwork system. The entire system of formwork and splints will transmit to the steel pipe struts. The steel pipe struts will transmit the force to the supporting beam and the end of the anchor bolts will bear all the forces acting from the supporting beam on them.
Select the steel column foot link when designing the work through analysis, the design engineer should apply the appropriate connection model calculation of the column anchor bolts.
+ Industrial factories with 1 or more spans with few floors will use jointed column bases
+ Low-rise workshop with brace frame will use the connection with the foot of the joint column
+ Multi-storey multi-span house using underground link column base
+ One-column garage with cantilevered beams using underground link columns
+ The pillar of the gate pillar will use the base of the underground connection column
The calculation of the column foot anchor bolts depends on the appropriate steel column foot connection model to meet the actual requirements of the actual working ability of each structure, construction conditions as well as simplify the process. The design process still ensures accuracy and reliability
If it is doubtful that the connection selected in the design model, the design engineer should analyze and check the internal displacement force in the structure to ensure that the steel column foot connection will work as expected so that it is safe.
